Current advances in UV-based advanced oxidation processes for the abatement of fluoroquinolone antibiotics in wastewater

Quinoxalin-2(1H)-one, as a significant heterocyclic unit, has been found important applications in synthetic chemistry, materials, natural products and pharmaceuticals because of their innate outstanding biological activities and excellent chemical characters [1], and their biological activities can be significantly influenced if the substituents is introduced into the N1- and C3-positions of the quinoxalin-2(1H)-one [2]. In particular, 3-substituted quinoxalin-2(1H)-ones have been developed into powerful drugs due to their strong pharmacological effects [3], such as ataquimast, antinicrobial, anticancer, Fxa coagulation inhibitors and glycogen phosphorylase inhibitor (Fig. 1) [4]. Therefore, a number of methods have been developed for their synthesis [5]. Generally, they are synthesized by cyclization of derivatives of aniline or 1, 2-diaminobenzene with suitable partners. However, the disadvantages including pre-functionalization of the partners and multi-step synthesis limit its application [6]. In recent years, direct C-H bond functionalization at the C3-position of quinoxalin-2(1H)-one has become a straightforward access to the 3-substituted quinoxalin-2(1H)-one derivatives, and various remarkable work has been achieved [7-12]. For instances, our group in 2019 reported a first example of oxidative C-H fluoroalkoxylation of quinoxalinones with fluoroalkyl alcohols under transition-metal and solvent-free conditions [8b]. This method can also be extended to the facile and efficient synthesis of histamine-4 receptor. The same year, Sun's group presented an efficient electrochemical approach for the C(sp²)–H phosphonation of quinoxalin-2(1H)-ones and C(sp³)–H phosphonation of xanthenes [9a]. More interestingly, the group of Pan disclosed a photocatalyst-free visible-light-promoted sulfenylation of quinoxalinones with thiols via cross-dehydrogenative coupling [10b]. Shortly after this discovery, He's group demonstrated a visible-light-promoted amidation of quinoxalin-2(1H)-ones [11b]. In a very recent contribution, a mild and eco-friendly visible-light-induced decarboxylative acylation of quinoxalin-2(1H)-ones with α-oxo carboxylic acids using ambient air as the sole oxidant at room temperature was also established by the same group [12a]. In sharp contrast, the alkenylation of quinoxalin-2(1H)-ones was rarely reported.

Figure 1

Figure 1.  Examples of quinoxalin-2(1H)-one skeleton-based bioactive molecules.

DownLoad: Full-Size Img PowerPoint

Photocatalysis has become a powerful strategy for organic synthesis due to the advantages of low energy consumption and environmental protection [13]. For example, MacMillan et al. in 2016 reported a photocatalyzed C-H arylation of aliphatic amines with aryl bromides, providing a complement to existing cross-coupling technologies [13a]. In 2021, He' group developed the first example of visible-light induced one-pot tandem reaction of arylacrylamides, CHF₂CO₂H and PhI(OAc)₂, affording an eco-friendly and practical method to access various difluoromethylated oxindoles [13b]. The same year, Jin and coworkers developed photocatalyst-free radical tandem cyclization of quinazolinones containing an unactivated alkene moiety with difluoro bromides under illumination, giving a practical method for the synthesis of fluorine-containing ring-fused quinazolinones [13f]. In recent years, with increasing attention to renewable energy, considerable efforts have been switched to the development of photocatalytic reactions that excited by the sunlight, which is known as a renewable and simple accessible light source [14]. Our research interests focus on the development of novel and effective methodologies for the direct modification ofN-containing heterocycles [15], herein, we demonstrated a direct alkenylation reaction between quinoxalin-2(1H)-ones and methyl ketones. Compared with our previous work [15a], this transformation was achieved through a combination of Mannich-type reaction and solar photocatalysis, which could be completed within 15min, providing a green and efficient solution for the synthesis of potentially bioactive compounds that containing a 3, 4-dihydroquinoxalin-2(1H)-one structure (Scheme 1b).

Scheme 1

Scheme 1.  Modification of quinoxalin-2(1H)-ones by C-H functionalization.

DownLoad: Full-Size Img PowerPoint

1-Methylquinoxalin-2(1H)-one (1a) and acetone (2a) were chosen as starting materials to screen the reaction conditions. The target product (3a) was obtained in 80% yield when the reaction was performed by using 25mol% of CH₃SO₃H as a catalyst under the irradiation of sunlight for 15min (Table 1, entry 1). Other acid catalyst, such as CF₃COOH and HBF₄ gave the relative lower yield under the same conditions (Table 1, entries 2 and 3). No product was obtained in the absence of any acid catalyst (Table 1, entry 4). When used MeCN or DMF as solvent and 2.0 equiv. of acetone as substrate, 76% or 52% yield was obtained respectively (Table 1, entries 5 and 6). Extended reaction time to 30min did not enhanced product yield (Table 1, entry 7). There was no desired product generated when the reaction was carried out under dark condition (Table 1, entry 8).

Table 1

Table 1.  Screening of reaction conditions.^a

DownLoad: CSV

With the optimum reaction conditions in hands, we then examined the substrate scope of the reaction by employing various quinoxalin-2(1H)-ones (1) with acetone (2a) (Scheme 2). Firstly, the N-substituted groups such as N-methyl, N-ethyl, N-cyclopropylmethyl, N-keto and N-ester were well compatible under the standard conditions, giving the desired products (3a-e) in 72%–80% yields. It is worth mentioning that quinoxalin-2(1H)-one with a sensitive allyl group, which could be further functionalized, also could give the product (3f) in 69% yield. A wide range of quinoxalin-2(1H)-ones with different benzyl groups, bearing both electron-donating and electron-withdrawing substituents at ortho-, meta-, or para-position could undergo the reaction smoothly, affording the corresponding products (3g–n) in 40%–72% yields. Importantly, the N-free quinoxalin-2(1H)-one could undergo the reaction smoothly, providing the product (3o) in 45% yield. Besides, plenty of quinoxalin-2(1H)-ones that bear the functional groups including methyl, halogen, tert-butyl, methoxy or trifluoromethyl at C5-, C6- or C7-position also gave the desired products in satisfactory yield (3p-3w). To expand the substrate scope of N-heterocycles, we also tested quinoline, isoquinoline, quinoxaline, benzimidazole and benzothiazole under standard conditions, however, no corresponding product was obtained (see Supporting information).

Scheme 2

Scheme 2.  Substrate scope of quinoxalin-2(1H)-ones. Reaction conditions: 1 (0.2 mmol), 2a (1.0 mL), CH₃SO₃H (25 mol%), open flask, sunlight, room temperature, 15 min. Isolated yields. ^a Reaction was performed on a 1 mmol scale.

DownLoad: Full-Size Img PowerPoint

Subsequently, we evaluated the substrate scope of methyl ketones for the reaction (Scheme 3). To reduce the dosage of reactant, the reactions were performed with 2.0 equiv. of methyl ketones by using acetonitrile as solvent. To our delight, both long-chain and cycloalkyl methyl ketones could undergo the reaction smoothly, giving the corresponding products (3x–3ad) in 58%–79% yields. The molecular structure of 3y was confirmed by X-ray crystallographic analysis (CCDC: 2060383). It was found that the molecular structure was more stable in (Z)-configuration probably because the effect of hydrogen bond interaction between amine and carbonyl group. Then, we found that cyclopentanone skeleton could also react with quinoxalin-2(1H)-one smoothly to deliver the target products (3ae and 3af) in moderate yield. The subsequent exploration found that the aryl methyl ketones, such as acetophenone, 1-(furan-2-yl)ethan-1-one and 1-(thiophen-2-yl)ethan-1-one were also could be converted into target products (3ag-3ai) in acceptable yields. Unfortunately, the substrates like ethyl acetate, acetonitrile, nitromethane, ethyl acetoacetate, and acetylacetone were not compatible under standard conditions (Supporting information).

Scheme 3

Scheme 3.  Substrate scope of methyl ketones. Reaction conditions: 1a (0.2 mmol), 2 (2.0 equiv.), CH₃SO₃H (25 mol%), MeCN (1.0 mL), open flask, sunlight, room temperature, 15min. Isolated yields.

DownLoad: Full-Size Img PowerPoint

To show the synthetic utility of this protocol, a gram-scale synthesis experiment was performed to give the target product (3a) in 75% yield (Scheme 4). Interestingly, the anticancer compound (3aj) and antimicrobial compound (3ak) were obtained in moderate yields by using our strategy [16]. Moreover, since the molecules that bearing a 3, 4 dihydroquinoxalin-2(1H)-one framework are a promising class of biologically active compounds, in this regard, several bioactive molecules such as naproxen derivative, frambinone, ibuprofen derivative, vanillylacetone, nabumetone and pregnenolone acetate were selected to react with 1-methylquinoxalin-2(1H)-one directly, providing the potentially active molecules (3al-3aq) in 52%–70% yields.

Scheme 4

Scheme 4.  Gram-scale synthesis and application. Reaction conditions: 1a (0.2mmol), 2 (2.0 equiv.), CH₃SO₃H (25mol%), MeCN (1.0mL), open flask, sunlight, room temperature, 15min. Isolated yields.

DownLoad: Full-Size Img PowerPoint

To study the reaction mechanism, a series of control experiments were carried out. Product 4 was generated instead of target product 3a when the reaction was performed under nitrogen atmosphere (Scheme 5). This result showed that oxygen in air was included in the subsequent oxidation process. To confirm the assumption, the oxidation process of compound 4 was studied. First, target product 3 was formed in 0%, 79% and 82% yields when the reaction performed under nitrogen, air or oxygen atmosphere respectively (Scheme 5). Second, the reaction was inhibited when singlet oxygen inhibitor (NaN₃) was involved in the transformation (Scheme 5). Furthermore, compound 4 could not be converted into target product 3 when the reaction was performed in dark condition (Scheme 5). These experimental results strongly supported that the singlet oxygen ¹O₂, which was generated from triplet oxygen ³O₂ through photocatalysis, serves as the real oxidant.

Scheme 5

Scheme 5.  Control experiments.

DownLoad: Full-Size Img PowerPoint

On the basis of above results and previous reports [8-12], we proposed a possible mechanism for this reaction (Scheme 6). Firstly, substrate 1a was transformed into intermediate A through a protonation process. Meanwhile, acetone 2a was converted to the enol form B under acidic condition. Then, a Mannich-type reaction took place between intermediates A and B to give the intermediate C, which underwent a deprotonation process to provide the key compound 4. It was found that organic molecules that containing a quinoxalin-2(1H)-one skeleton could act as a photosensitizer to generate ¹O₂ from O₂ under the irradiation of visible light [12p]. In this regard, compounds1a, 4 or 3a was excited by visible light to provide the excited-species 1a^*, 4^* or 3a^*, which acted as a photosensitizer and underwent an energy transfer (ET) process with O₂ to give ¹O₂, along with the regeneration of ground-state compounds 1a, 4 or 3a. Finally, compound 4 underwent the single-electron-transfer (SET) process with ¹O₂ to give the desired product with the generation of H₂O₂, which was detected by H₂O₂ test paper (Supporting information) [12a] [17]. We proposed that the electron-withdrawing effects of carbonyl group that exists in quinoxalin-2(1H)-one skeleton lower down the electron cloud density of the enamine moiety, making it difficult to be oxidized and can survive under this H₂O₂ oxidation conditions.

Scheme 6

Scheme 6.  Plausible mechanism.

DownLoad: Full-Size Img PowerPoint

In conclusion, this study described a novel strategy for the olefination of quinoxalin-2(1H)-ones with methyl ketones. Various substrates were compatible under standard condition, providing the corresponding products in moderate to good yields. Control experiments revealed that a Mannich-type reaction and oxidative process were involved in the transformation.

Declaration of competing interest

The authors declare that they have no conflict of interest.

Acknowledgments

We thank the Natural Science Foundation of Zhejiang Province (No. LY21B060009) and the National Natural Science Foundation of China (No. 21871071) for financial support.

Appendix A. Supplementary data

Supplementary material related to this article can befound, in the online version, at doi:https://doi.org/10.1016/j.cclet.2021.04.016.

References

1. [1]

   S. Bhatt, S. Chatterjee, Environ. Pollut. 315 (2022) 120440.


2. [2]

   E.Y. Klein, T.P. Van Boeckel, E.M. Martinez, et al., Proc. Natl. Acad. Sci. U. S. A. 115 (2018) E3463–E3470.


3. [3]

   D. Schar, E.Y. Klein, R. Laxminarayan, et al., Sci. Rep. 10 (2020) 21878.  doi: 10.1038/s41598-020-78849-3


4. [4]

   Q.Q. Zhang, G.G. Ying, C.G. Pan, et al., Environ. Sci. Technol. 49 (2015) 6772–6782.  doi: 10.1021/acs.est.5b00729


5. [5]

   I.T. Carvalho, L. Santos, Environ. Int. 94 (2016) 736–757.


6. [6]

   X. Van Doorslaer, J. Dewulf, H. Van Langenhove, K. Demeestere, Sci. Total Environ. 500 (2014) 250–269.


7. [7]

   M. Zou, W. Tian, J. Zhao, et al., Process Saf. Environ. Prot. 160 (2022) 116–129.  doi: 10.1016/j.psep.2022.02.013


8. [8]

   S. Li, W. Shi, W. Liu, et al., Sci. Total Environ. 615 (2018) 906–917.  doi: 10.1016/j.scitotenv.2017.09.328


9. [9]

   S. Li, Y. Liu, Y. Wu, et al., Natl. Sci. Open. 1 (2022) 20220029.  doi: 10.1360/nso/20220029


10. [10]

    E.M. Golet, A.C. Alder, W. Giger, Environ. Sci. Technol. 36 (2002) 3645–3651.  doi: 10.1021/es0256212


11. [11]

    M. Sturini, A. Speltini, F. Maraschi, et al., Chemosphere 134 (2015) 313–318.  doi: 10.1016/j.chemosphere.2015.04.081


12. [12]

    Z. Li, J. Wang, J. Chang, et al., Sci. Total Environ. 857 (2023) 159172.  doi: 10.1016/j.scitotenv.2022.159172


13. [13]

    R. Anjali, S. Shanthakumar, J. Environ. Manage. 246 (2019) 51–62.  doi: 10.1016/j.jenvman.2019.05.090


14. [14]

    Y. Zhang, Y.G. Zhao, F. Maqbool, Y. Hu, J. Water Process. Eng. 45 (2022) 102496.  doi: 10.1016/j.jwpe.2021.102496


15. [15]

    Y. Chuang, S. Chen, C. Chinn, W. Mitch, Environ. Sci. Technol. 51 (2017) 13859–13868.  doi: 10.1021/acs.est.7b03570


16. [16]

    C. Wang, N. Moore, K. Bircher, et al., Water Res. 161 (2019) 448–458.  doi: 10.1016/j.watres.2019.06.033


17. [17]

    J. Rodriguez-Chueca, S. Varella della Giustina, J. Rocha, et al., Sci. Total Environ. 652 (2019) 1051–1061.  doi: 10.1016/j.scitotenv.2018.10.223


18. [18]

    J. Rodríguez-Chueca, E. Laski, C. García-Cañibano, et al., Sci. Total Environ. 630 (2018) 1216–1225.  doi: 10.1016/j.scitotenv.2018.02.279


19. [19]

    Y. Chen, J. Yang, L. Zeng, M. Zhu, Crit. Rev. Environ. Sci. Technol. 52 (2022) 1401–1448.  doi: 10.1080/10643389.2020.1859289


20. [20]

    S. Shurbaji, P.T. Huong, T.M. Altahtamouni, Catalysts 11 (2021) 437.  doi: 10.3390/catal11040437


21. [21]

    Y. Gou, P. Chen, L. Yang, et al., Chemosphere 270 (2021) 129481.  doi: 10.1016/j.chemosphere.2020.129481


22. [22]

    X. Liu, Y. Zhou, J. Zhang, et al., Chem. Eng. J. 347 (2018) 379–397.  doi: 10.1016/j.cej.2018.04.142


23. [23]

    T. Song, G. Li, R. Hu, et al., Catalysts 12 (2022) 1025.  doi: 10.3390/catal12091025


24. [24]

    Z. Lu, Y. Ling, W. Sun, et al., Environ. Pollut. 308 (2022) 119673.  doi: 10.1016/j.envpol.2022.119673


25. [25]

    X. Luo, B. Zhang, Y. Lu, et al., J. Hazard. Mater. 421 (2022) 126682.  doi: 10.1016/j.jhazmat.2021.126682


26. [26]

    H.D.M. Tran, S. Boivin, H. Kodamatani, et al., Chemosphere 286 (2022) 131682.  doi: 10.1016/j.chemosphere.2021.131682


27. [27]

    R. Shankar, W.J. Shim, J.G. An, U.H. Yim, Water Res. 68 (2015) 304–315.  doi: 10.1016/j.watres.2014.10.012


28. [28]

    W. Qiu, M. Zheng, J. Sun, et al., Sci. Total Environ. 651 (2019) 1457–1468.  doi: 10.1016/j.scitotenv.2018.09.315


29. [29]

    Y. Zhang, K. Huang, Y. Zhu, et al., RSC Adv. 12 (2022) 10088–10096.  doi: 10.1039/d2ra00199c


30. [30]

    X. Zeng, Y. Meng, X. Sun, et al., J. Environ. Chem. Eng. 9 (2021) 106608.  doi: 10.1016/j.jece.2021.106608


31. [31]

    X. Ao, W. Wang, W. Sun, et al., Water Res. 203 (2021) 117458.  doi: 10.1016/j.watres.2021.117458


32. [32]

    K. Guo, Z. Wu, S. Yan, et al., Water Res. 147 (2018) 184–194.  doi: 10.1016/j.watres.2018.08.048


33. [33]

    H. Milh, X. Yu, D. Cabooter, R. Dewil, Sci. Total Environ. 764 (2021) 144510.  doi: 10.1016/j.scitotenv.2020.144510


34. [34]

    H. Yang, Y. Li, Y. Chen, et al., Water Environ. Res. 91 (2019) 1576–1588.  doi: 10.1002/wer.1144


35. [35]

    H. Xue, S. Gao, N. Zheng, et al., Water Sci. Technol. 79 (2019) 2387–2394.  doi: 10.2166/wst.2019.240


36. [36]

    C.C. Lin, H.Y. Lin, Desalin. Water Treat. 167 (2019) 170–175.  doi: 10.5004/dwt.2019.24602


37. [37]

    J. Deng, G. Wu, S. Yuan, et al., J. Photochem. Photobiol. A: Chem. 371 (2019) 151–158.  doi: 10.1016/j.jphotochem.2018.10.043


38. [38]

    X. Zhang, K. Guo, Y. Wang, et al., Chem. Eng. J. 400 (2020) 125222.  doi: 10.1016/j.cej.2020.125222


39. [39]

    J. Lu, J. Li, J. Xu, et al., J. Water Process Eng. 44 (2021) 102324.  doi: 10.1016/j.jwpe.2021.102324


40. [40]

    H. Liu, Y. Gao, J. Wang, et al., Chemosphere 276 (2021) 130220.  doi: 10.1016/j.chemosphere.2021.130220


41. [41]

    D. Krakko, A. Illes, V. Licul-Kucera, et al., Chemosphere 275 (2021) 130080.  doi: 10.1016/j.chemosphere.2021.130080


42. [42]

    Q. Ping, T. Yan, L. Wang, et al., Water Res. 210 (2022) 118019.  doi: 10.1016/j.watres.2021.118019


43. [43]

    Q. Wu, Z. Que, Z. Li, et al., J. Hazard. Mater. 359 (2018) 414–420.  doi: 10.1016/j.jhazmat.2018.07.041


44. [44]

    C. Zhao, Y. Li, H. Chu, et al., J. Hazard. Mater. 419 (2021) 126466.  doi: 10.1016/j.jhazmat.2021.126466


45. [45]

    K. Saravanakumar, C.M. Park, Chem. Eng. J. 423 (2021) 130076.  doi: 10.1016/j.cej.2021.130076


46. [46]

    V.T. Le, V.A. Tran, D.L. Tran, et al., Chemosphere 270 (2021) 129417.  doi: 10.1016/j.chemosphere.2020.129417


47. [47]

    J. Lei, B. Chen, L. Zhou, et al., Chem. Eng. J. 400 (2020) 125902.  doi: 10.1016/j.cej.2020.125902


48. [48]

    J. Li, Z. Xia, D. Ma, et al., J. Colloid Interface Sci. 586 (2021) 243–256.  doi: 10.1016/j.jcis.2020.10.088


49. [49]

    Q. Chen, M. Zhang, J. Li, et al., Chem. Eng. J. 389 (2020) 124476.  doi: 10.1016/j.cej.2020.124476


50. [50]

    Q. Zhang, F. Han, Y. Yan, et al., Appl. Surf. Sci. 485 (2019) 547–553.  doi: 10.1016/j.apsusc.2019.04.185


51. [51]

    R. Du, P. Chen, Q. Zhang, G. Yu, Chemosphere 273 (2021) 128435.  doi: 10.1016/j.chemosphere.2020.128435


52. [52]

    X. Zeng, X. Sun, Y. Yu, et al., Chem. Eng. J. 378 (2019) 122226.  doi: 10.1016/j.cej.2019.122226


53. [53]

    L. Yang, Y. Xiang, F. Jia, et al., Appl. Catal. B: Environ. 292 (2021) 120198.  doi: 10.1016/j.apcatb.2021.120198


54. [54]

    Y. Tian, X. He, W. Chen, et al., Sci. Total Environ. 723 (2020) 138144.  doi: 10.1016/j.scitotenv.2020.138144


55. [55]

    O. Autin, C. Romelot, L. Rust, et al., Chemosphere 92 (2013) 745–751.  doi: 10.1016/j.chemosphere.2013.04.028


56. [56]

    S. Li, J. Hu, Water Res. 132 (2018) 320–330.  doi: 10.1016/j.watres.2017.12.065


57. [57]

    T.K. Kim, T. Kim, H. Park, et al., Chem. Eng. J. 394 (2020) 124803.  doi: 10.1016/j.cej.2020.124803


58. [58]

    S. Li, T. Huang, P. Du, et al., Water Res. 185 (2020) 116286.  doi: 10.1016/j.watres.2020.116286


59. [59]

    S. Guerra-Rodriguez, A.R. Lado Ribeiro, R.S. Ribeiro, et al., Sci. Total Environ. 770 (2021) 145299.  doi: 10.1016/j.scitotenv.2021.145299


60. [60]

    P. Chen, L. Blaney, G. Cagnetta, et al., Environ. Sci. Technol. 53 (2019) 1564–1575.  doi: 10.1021/acs.est.8b05827


61. [61]

    D. Cheng, H. Liu, E. Yang, et al., Sci. Total Environ. 773 (2021) 145102.  doi: 10.1016/j.scitotenv.2021.145102


62. [62]

    X. Liu, Y. Liu, S. Lu, et al., Chem. Eng. J. 385 (2020) 123987.  doi: 10.1016/j.cej.2019.123987


63. [63]

    W.K. Ye, F.X. Tian, B. Xu, et al., Sep. Purif. Technol. 280 (2022) 119846.  doi: 10.1016/j.seppur.2021.119846


64. [64]

    D.A. Armstrong, R.E. Huie, W.H. Koppenol, et al., Pure Appl. Chem. 87 (2015) 1139–1150.  doi: 10.1515/pac-2014-0502


65. [65]

    J. Lee, U. von Gunten, J.H. Kim, Environ. Sci. Technol. 54 (2020) 3064–3081.  doi: 10.1021/acs.est.9b07082


66. [66]

    T. Luukkonen, T. Heyninck, J. Rämö, U. Lassi, Water Res. 85 (2015) 275–285.  doi: 10.1016/j.watres.2015.08.037


67. [67]

    H. Zhang, L. Chen, P. Du, et al., Environ. Sci. Technol. 58 (2024) 3506–3519.


68. [68]

    M. Sturini, F. Maraschi, A. Cantalupi, et al., Materials 13 (2020) 537.  doi: 10.3390/ma13030537


69. [69]

    M. Eskandari, N. Goudarzi, S.G. Moussavi, Water Environ. J. 32 (2018) 58–66.  doi: 10.1111/wej.12291


70. [70]

    E.A. Serna-Galvis, Y. Avila-Torres, M. Ibanez, et al., Water 13 (2021) 2154.  doi: 10.3390/w13162154


71. [71]

    L. Pretali, F. Maraschi, A. Cantalupi, et al., Catalysts 10 (2020) 628.  doi: 10.3390/catal10060628


72. [72]

    A. Kaur, A. Umar, W.A. Anderson, S.K. Kansal, J. Photochem. Photobiol. A: Chem. 360 (2018) 34–43.  doi: 10.1016/j.jphotochem.2018.04.021


73. [73]

    A. Siddique, M.B. Tahir, I. Shahid, et al., Appl. Nanosci. 12 (2022) 1613–1626.  doi: 10.1007/s13204-021-02313-5


74. [74]

    L. Wolski, K. Grzelak, M. Munko, et al., Appl. Surf. Sci. 563 (2021) 150338.  doi: 10.1016/j.apsusc.2021.150338


75. [75]

    N. Kaur, A. Verma, I. Thakur, S. Basu, Chemosphere 276 (2021) 130180.  doi: 10.1016/j.chemosphere.2021.130180


76. [76]

    K. Qin, Q. Zhao, H. Yu, et al., Environ. Res. 199 (2021) 111360.  doi: 10.1016/j.envres.2021.111360


77. [77]

    T. Senasu, T. Narenuch, K. Wannakam, et al., J. Mater. Sci.: Mater. Electron. 31 (2020) 9685–9694.  doi: 10.1007/s10854-020-03514-4


78. [78]

    T. Chankhanittha, V. Somaudon, T. Photiwat, et al., J. Phys. Chem. Solids. 153 (2021) 109995.  doi: 10.1016/j.jpcs.2021.109995


79. [79]

    W. Liu, J. Zhou, J. Yao, Ecotoxicol. Environ. Saf. 190 (2020) 110062.  doi: 10.1016/j.ecoenv.2019.110062


80. [80]

    X. Zheng, S. Xu, Y. Wang, et al., J. Colloid Interface Sci. 527 (2018) 202–213.  doi: 10.1016/j.jcis.2018.05.054


81. [81]

    S. Moles, J. Berges, M.P. Ormad, et al., Environ. Sci. Pollut. Res. 28 (2021) 24167–24179.  doi: 10.1007/s11356-021-12542-4


82. [82]

    X. Huang, S. Wu, S. Tang, et al., J. Mol. Liq. 317 (2020) 113961.  doi: 10.1016/j.molliq.2020.113961


83. [83]

    C. Zhang, M. Jia, Z. Xu, et al., Chem. Eng. J. 430 (2022) 132652.  doi: 10.1016/j.cej.2021.132652


84. [84]

    Q. Wu, M.S. Siddique, Y. Guo, et al., Appl. Catal. B: Environ. 286 (2021) 119950.  doi: 10.1016/j.apcatb.2021.119950


85. [85]

    C. Yang, X. Wang, L. Zhang, et al., J. Taiwan Inst. Chem. Eng. 115 (2020) 117–127.  doi: 10.1016/j.jtice.2020.09.036


86. [86]

    L. Rizzo, Environ. Sci. Water Res. Technol. 8 (2022) 2145–2169.  doi: 10.1039/d2ew00146b


87. [87]

    H. Luo, Y. Zeng, D. He, X. Pan, Chem. Eng. J. 407 (2021) 127191.  doi: 10.1016/j.cej.2020.127191


88. [88]

    Y. Jiang, J. Ran, K. Mao, et al., Ecotoxicol. Environ. Saf. 236 (2022) 113464.  doi: 10.1016/j.ecoenv.2022.113464


89. [89]

    S.K. Mondal, A.K. Saha, A. Sinha, J. Cleaner Prod. 171 (2018) 1203–1214.  doi: 10.1016/j.jclepro.2017.10.091


90. [90]

    H. Dan, Y. Kong, Q. Yue, et al., Chem. Eng. J. 420 (2021) 127634.  doi: 10.1016/j.cej.2020.127634


91. [91]

    W. He, Z. Li, S. Lv, et al., Chem. Eng. J. 409 (2021) 128274.  doi: 10.1016/j.cej.2020.128274


92. [92]

    W. Li, Y. Wang, J. Chen, et al., Appl. Catal. B: Environ. 302 (2022) 120882.  doi: 10.1016/j.apcatb.2021.120882


93. [93]

    A. Hassani, J. Scaria, F. Ghanbari, P.V. Nidheesh, Environ. Res. 217 (2023) 114789.  doi: 10.1016/j.envres.2022.114789


94. [94]

    J. Yang, M. Zhu, D.D. Dionysiou, Water Res. 189 (2021) 116627.  doi: 10.1016/j.watres.2020.116627


95. [95]

    Y. Sun, D.W. Cho, N.J.D. Graham, et al., Sci. Total Environ. 664 (2019) 312–321.  doi: 10.1016/j.scitotenv.2019.02.006


96. [96]

    E. Ngumba, A. Gachanja, T. Tuhkanen, Water Environ. J. 34 (2020) 692–703.  doi: 10.1111/wej.12612


97. [97]

    L. Wang, J. Wei, Y. Li, et al., Chem. Eng. J. 477 (2023) 147051.  doi: 10.1016/j.cej.2023.147051


98. [98]

    T. Luukkonen, S.O. Pehkonen, Crit. Rev. Environ. Sci. Technol. 47 (2017) 1–39.  doi: 10.1080/10643389.2016.1272343


99. [99]

    X. Ao, X. Zhang, S. Li, et al., J. Hazard. Mater. 445 (2023) 130480.  doi: 10.1016/j.jhazmat.2022.130480


100. [100]

     Z. Diao, J. Jin, M. Zou, et al., Sep. Purif. Technol. 278 (2021) 119620.  doi: 10.1016/j.seppur.2021.119620


101. [101]

     Z.H. Diao, S.T. Huang, X. Chen, et al., J. Cleaner Prod. 330 (2022) 129806.  doi: 10.1016/j.jclepro.2021.129806


102. [102]

     J. Wu, J. Bai, Z. Wang, et al., Environ. Technol. 43 (2022) 95–106.  doi: 10.1080/09593330.2020.1779353


103. [103]

     H. Tang, Z. Dai, X. Xie, et al., Chem. Eng. J. 356 (2019) 472–482.  doi: 10.1016/j.cej.2018.09.066


104. [104]

     Y. h. Tian, N. Jia, L. Zhou, et al., Chemosphere 288 (2022) 132627.  doi: 10.1016/j.chemosphere.2021.132627


105. [105]

     D. Li, Z. Feng, B. Zhou, et al., Sci. Total Environ. 844 (2022) 157162.  doi: 10.1016/j.scitotenv.2022.157162


106. [106]

     P. Wang, H. Zhang, Z. Wu, et al., Chin. Chem. Lett. 34 (2023) 108722.  doi: 10.1016/j.cclet.2023.108722


107. [107]

     F. Wang, Y. Feng, P. Chen, et al., Appl. Catal. B: Environ. 227 (2018) 114–122.  doi: 10.1016/j.apcatb.2018.01.024


108. [108]

     G. Wang, Y. Li, J. Dai, N. Deng, Environ. Sci. Pollut. Res. 29 (2022) 48522–48538.  doi: 10.1007/s11356-022-19269-w


109. [109]

     H. Abdelraouf, J. Ding, J. Ren, et al., Process Saf. Environ. Prot. 168 (2022) 892–906.  doi: 10.1016/j.psep.2022.10.069


110. [110]

     M. Kumaresan, V. Saravanan, M. Swaminathan, Inorg. Chem. Commun. 142 (2022) 109706.  doi: 10.1016/j.inoche.2022.109706


111. [111]

     K. Jutarvutikul, C. Sakulthaew, C. Chokejaroenrat, et al., Aquacult. Eng. 94 (2021) 102174.  doi: 10.1016/j.aquaeng.2021.102174


112. [112]

     A.S. Giri, A.K. Golder, J. Environ. Sci. 80 (2019) 82–92.  doi: 10.1016/j.jes.2018.09.016


113. [113]

     C. Wang, J. Zhang, J. Du, et al., J. Hazard. Mater. 416 (2021) 125893.  doi: 10.1016/j.jhazmat.2021.125893


114. [114]

     G. Harini, M.K. Okla, I.A. Alaraidh, et al., Chemosphere 303 (2022) 134963.  doi: 10.1016/j.chemosphere.2022.134963


115. [115]

     X. Ao, W. Liu, W. Sun, et al., Chem. Eng. J. 345 (2018) 87–97.  doi: 10.1016/j.cej.2018.03.133


116. [116]

     Y. Qi, R. Qu, J. Liu, et al., Chemosphere 237 (2019) 124484.  doi: 10.1016/j.chemosphere.2019.124484


117. [117]

     S.P. Asu, N.K. Sompalli, S. Kuppusamy, et al., Mater. Today Sustain. 19 (2022) 100189.


118. [118]

     N. Yin, H. Chen, X. Yuan, et al., J. Hazard. Mater. 436 (2022) 129317.  doi: 10.1016/j.jhazmat.2022.129317


119. [119]

     H. Guo, N. Gao, Y. Yang, Y. Zhang, Chem. Eng. J. 292 (2016) 82–91.  doi: 10.1016/j.cej.2016.01.009


120. [120]

     M. Kamagate, A.A. Assadi, T. Kone, et al., J. Hazard. Mater. 346 (2018) 159–166.  doi: 10.1016/j.jhazmat.2017.12.011


121. [121]

     Y. Park, S. Kim, J. Kim, et al., Water 14 (2022) 958.  doi: 10.3390/w14060958


122. [122]

     F.H. Borba, A. Schmitz, L. Pellenz, et al., J. Environ. Chem. Eng. 6 (2018) 6979–6988.  doi: 10.1016/j.jece.2018.10.068


123. [123]

     Y. Zhu, M. Wei, Z. Pan, et al., Sci. Total Environ. 705 (2020) 135960.  doi: 10.1016/j.scitotenv.2019.135960


124. [124]

     S. Li, J.Y. Hu, J. Hazard. Mater. 318 (2016) 134–144.  doi: 10.1016/j.jhazmat.2016.05.100


125. [125]

     F. Tan, D. Sun, J. Gao, et al., J. Hazard. Mater. 244 (2013) 750–757.


126. [126]

     Z. Li, X. Yuan, H. Tang, et al., Environ. Sci. Water Res. Technol. 8 (2022) 2744–2760.  doi: 10.1039/d2ew00320a


127. [127]

     A. Wang, H. Wang, H. Deng, et al., Appl. Catal. B: Environ. 248 (2019) 298–308.  doi: 10.1016/j.apcatb.2019.02.034


128. [128]

     Y. Yu, K. Liu, Y. Zhang, et al., Int. J. Environ. Res. Public Health 19 (2022) 4793.  doi: 10.3390/ijerph19084793


129. [129]

     F. Wang, X. Yu, M. Ge, S. Wu, Chem. Eng. J. 384 (2020) 123381.  doi: 10.1016/j.cej.2019.123381


130. [130]

     O. Gomes Junior, V.M. Silva, A.E.H. Machado, et al., J. Environ. Manage. 213 (2018) 20–26.  doi: 10.1016/j.jenvman.2018.02.041
