Green-synthesized, low-cost tetracyanodiazafluorene (TCAF) as electron injection material for organic light-emitting diodes

Citation: Yang Bing, Zhao Jianfeng, Wang Zepeng, Yang Zhenlin, Lin Zongqiong, Zhang Yanni, Li Jiewei, Xie Linghai, An Zhongfu, Zhang Hongmei, Weng Jiena, Huang Wei. Green-synthesized, low-cost tetracyanodiazafluorene (TCAF) as electron injection material for organic light-emitting diodes[J]. Chinese Chemical Letters, 2019, 30(11): 1969-1973. doi: 10.1016/j.cclet.2019.08.054 shu

Green-synthesized, low-cost tetracyanodiazafluorene (TCAF) as electron injection material for organic light-emitting diodes

English

Green-synthesized, low-cost tetracyanodiazafluorene (TCAF) as electron injection material for organic light-emitting diodes

a.
Key Laboratory of Flexible Electronics(KLOFE) & Institute of Advanced Materials(IAM), Jiangsu National Synergetic Innovation Center for Advanced Materials(SICAM), Nanjing Tech University(Nanjing Tech), Nanjing 211816, China
b.
Key Laboratory for Organic Electronics & Information Displays(KLOEID) and Institute of Advanced Materials, Nanjing University of Posts & Telecommunications, Nanjing 210023, China
c.
Shaanxi Institute of Flexible Electronics(SIFE), Northwestern Polytechnical University(NPU), Xi'an 710072, China
^*Corresponding authors.
^** Corresponding author at: Key Laboratory of Flexible Electronics (KLOFE) & Institute of Advanced Materials (IAM)
Jiangsu National Synergetic Innovation Center for Advanced Materials (SICAM)
Nanjing Tech University (Nanjing Tech)
Nanjing 211816
China.
E-mail addresses: iamjfzhao@outlook.com (J. Zhao)
iamhmzhang@njupt.edu.cn (H. Zhang)
iamjnweng@nwpu.edu.cn (J. Weng)
iamwhuang@njtech.edu.cn (W. Huang).
¹ These two authors contributed equally to this work.
Received Date: 05 June 2019
Accepted Date: 29 August 2019
Revised Date: 29 July 2019
Available Online: 22 November 2019

Abstract: Two electron-deficient azaacenes including di- and tetra-cyanodiazafluorene (DCAF and TCAF) with the advantages of deep lowest unoccupied molecular orbital (LUMO), green-synthesis, low-cost, simply purification method, excellent yields have been obtained, characterized and used as electron injection materials (EIMs) in three groups of electroluminescence devices. Device B with TCAF as EIM exhibited the best performance including turn-on voltage of 5.0 V, stronger maximum luminance intensity of 31, 549 cd/m², higher luminance efficiency of 62.34 cd/A and larger power efficiency of 21.74 lm/W which are 0.53, 6.7, 9.3 and 15.3 times than that of device A with DCAF as EIMs, respectively. The enhanced interfacial electron injection ability of TCAF than that of DCAF is supported by its better electron mobility in electron-only device, deeper LUMO (-4.52 eV), and stronger electronic affinity. Best external quantum efficiency of 16.56% was achieved with optimized thicknesses of TCAF as EIM and TPBi as electron transporting layer. As a new comer of acceptor family, TCAF would push forward organic electronics with more fascinating and significant applications.
